GE 869-E-P5-P5-B5-H-S-S-A-L-A-M-M-P-F-A-SE-N-N-B-N-1 Industrial Motor Protection Relay

Description

External Dimensions:H7.93” (201.51 mm) x W6.62” (138.2 mm) x D9.62” (244.2 mm)

Operating Temperature:-40°C to 60°C | -40°F to 140°F

Storage Temperature:-40°C to 85°C | -40°F to 185°F

Humidity Standards:Operating up to 95% (non-condensing) @ 55°C (131°F)

Ground Currents:5 A

Phase Currents:5 A

Weight:Net: 2.9 kg (6.4 lbs) | Gross: 4.0 kg (8.6 lbs)

    The GE 869-E-P5-P5-B5-H-S-S-A-L-A-M-M-P-F-A-SE-N-N-B-N-1 is a robust motor protection relay designed for industrial applications requiring high reliability and performance under extreme conditions. Equipped with a front panel rated at IP54 and coated with a protective conformal coating, this relay is built to withstand harsh environments without failure-prone components such as electrolytic capacitors.

    Key Features:

    – Comprehensive protection against overvoltage, undervoltage, phase imbalance, and thermal overload.

    – Directional power relay, power factor relay, and negative sequence overvoltage detection for precise monitoring.

    – Virtual inputs and breaker/contactor control for enhanced flexibility and control.

    – Monitoring features including motor start reports, health checks, and data logging for proactive maintenance.

    Installation is straightforward, with clear instructions provided for quick setup and integration into existing systems. Its compact design and lightweight make it ideal for space-constrained installations.
