General Electric IS200EBRGH2A Bridge and Protection Module, EBRG Interface

Description

Board Type:Bridge and Protection Module

Functional Acronym/Abbreviation:EBRG

Interfaces:Control to the Power Bridge

Number of EBRGs per PCM:One

Power Source:125 VDC from EDIS Power Supply

Series Manual:GEH-6781L Thyristor Systems

Thyristor Systems:42, 52, and 77 mm

    This Bridge and Protection Module is essential for managing thyristor systems within the power bridge, ensuring efficient and controlled power distribution. Designed by GE, it is known for its reliability and robustness, making it a key component in industrial control applications. The module includes on-board green and red LED indicators for easy status monitoring. It interfaces directly with the power bridge, providing necessary control signals to ensure optimal performance. Its compact design allows for easy integration into existing systems without requiring significant modifications. The GE IS200EBRGH2A is built using high-quality materials, ensuring durability and longevity. Installation is straightforward, with detailed manuals provided for guidance. By utilizing this module, industries can achieve enhanced control over their power systems, leading to improved efficiency and safety.
