Description
Bandwidth:500 MHz
Sample Rate:2.5 GS/s
Channel Count:4
Waveform Capture Rate:20,000 wfm/s
Record Length per Channel:10 Mpts
Vertical Sensitivity:2 mV/div to 10 V/div
Input Impedance:1 MΩ ±2%
Horizontal Time Base Range:2 ns/div to 50 s/div
Trigger Types:Edge, Pulse Width, Runt, Logic, TV, Parallel, Window, Sequence, and more
Experience superior performance with the Tektronix DPO3054 Digital Phosphor Oscilloscope. Its advanced design includes a high bandwidth and sampling rate, making it ideal for debugging complex systems.
This oscilloscope is equipped with four analog channels, providing flexibility and versatility for a wide range of applications.
With a record length of 10 million points per channel, you can capture and analyze even the most intricate signal details with precision.
The high waveform capture rate ensures that you don’t miss any transient events, allowing for quick and accurate analysis.
The 9-inch TFT-LCD display with 800 x 480 resolution provides clear and detailed visuals, enhancing your overall measurement experience.
