Description
Model Number:Triconex 3511
Type:TMR, PI
Input Signals:8, non-commoned
Resolution:16 bits
Accuracy:± 0.01%
Input Frequency Range:1,000 Hz to 20,000 Hz
Input Characteristics:AC coupled, balanced differential
Update Rate:25 ms, typical
Impedance (Load):> 8 kW, 20 kW typical
Common Mode Range:-100 VDC to +100 VDC peak-to-peak
Normal Mode Range:1.5 V to 200 V peak-to-peak
Overrange Protection:±150 VDC, continuous
Hysteresis:150 millivolts, typical
Wave Shape:Sine, square, pulse, etc.
The TRICONEX 3511 TMR Input/Output Module is engineered for demanding industrial environments.
Its robust design ensures reliable operation even under extreme conditions.
With high resolution and precision, this module is capable of handling various wave shapes including sine, square, and pulse, making it suitable for a wide range of applications.
Featuring TMR technology, it provides enhanced safety and redundancy, ensuring uninterrupted system performance.
The module’s ability to process up to 8 non-commoned input signals simultaneously makes it a versatile solution for complex automation setups.
Designed with a focus on durability and efficiency, the TRICONEX 3511 module is an essential choice for industries requiring high standards of control and monitoring.
