Description
Power Supply Method:Dual-line or single power line
Input Voltage Range (AC):100-120 V, 220-240 V
Frequency Range (AC):50/60 Hz
Input Voltage (DC):24 V
Power Consumption (AC 100-120 V):80 VA
Power Consumption (AC 220-240 V):110 VA
Power Consumption (DC 24 V):1.7 A
Grounding:M4 screw terminal connection
Contact Output:M4 screw terminal connection
Net Connection Side:T-junction BNC connection
IP Side:UTP cable (CAT5e or better)
Weight:Approx. 5.8 kg
The AVR10D-Q22020 is part of the STARDOM series from Yokogawa, renowned for its reliability and performance in industrial automation. This advanced control system offers a robust power supply through M4 screw terminal connections, ensuring stable operation under varying conditions. Its grounding feature further enhances safety and performance. The contact output through M4 screw terminal connections provides reliable connectivity for various industrial applications.
Designed for seamless integration, the Vnet/VLnet side employs a T-junction BNC connection, while the Vnet/IP side utilizes UTP cables (CAT5e or better) for optimal data transmission. As part of the Yokogawa Duplexed Vnet Router system, the AVR10D-Q22020 supports dual-line or single power lines, providing flexibility and redundancy in power supply.
This system is compatible with multiple voltage inputs including 100-120 V AC, 220-240 V AC, and 24 V DC, and operates efficiently across a wide range of frequencies (50/60 Hz). Its power consumption is optimized for energy efficiency, consuming 80 VA at 100-120 V AC, 110 VA at 220-240 V AC, and 1.7 A at 24 V DC.
With a weight of approximately 5.8 kg, the AVR10D-Q22020 is easy to install and maintain, making it a valuable addition to any industrial control setup. Its advanced features and reliable performance make it an essential component for modern industrial processes.
